The StarEFX WiFi Controller 2048 is the control core for StarEFX ceiling lighting effects. Supplied pre-configured for PULSE and MATRIX panels, and for compatible RGBIC (addressable) LED strip integrations.

The controller includes a wide range of standard presets, with a few LightEFX customisations configured for StarEFX ceiling applications; including tailored animations and scene behaviour designed specifically for StarEFX installations.

Key features

• Customised for StarEFX PULSE and MATRIX ceiling lighting behaviour (LightEFX configured)

• WiFi control via WLED mobile app and web interface

• Supports addressable RGBIC / digital LED strip types (e.g. WS2812B, WS2815, SK6812, UCS2903B, SM16703)

• Audio-reactive capability via integrated microphone (where enabled in the StarEFX profile)

Technical specifications

• Input voltage: DC 5–12–24V

• Max output current: 15A total / 10A per channel

• Type-C input: 5V / 3A max (service / flashing / configuration use)

• Interfaces: UART/Type-C + DIY GPIO pins

• StarEFX rating: up to 2048 pixels (LightEFX configured capacity)

Use notes

• Intended for digital/addressable RGBIC loads (not for analogue constant-voltage RGB/RGBW strips).

• Ensure power supply sizing matches total LED load and installation method – see our 12V 5A power supply and 12V power supply options.

Works with: the StarEFX PULSE acoustic starlight panel, the StarEFX MATRIX fibre optic star ceiling panel and the 10mm RGBIC COB LED strip. Also available as a bundle: FCOB RGBW LED strip + WiFi controller. New to star ceilings? Browse our acoustic panels.
