A heavy-duty 12V DC constant-voltage LED driver designed for stable, long-life operation in demanding installs, including outdoor and landscape lighting applications. It comes in an IP67 waterproof enclosure and includes a 1 metre AU plug lead for straightforward site deployment.

Built for reliability, this driver offers high efficiency (up to 93%) and comprehensive protection features including surge protection, over-voltage, short circuit, and over-temperature protection. Output voltage can be adjusted via an onboard potentiometer to fine-tune the supply under real-world load and cable run conditions.

Key features

• IP67 waterproof with 1m AU plug lead

• Constant-voltage 12V DC output – 11.5A / 138W

• Efficiency up to 93%

• Protections: surge, over-voltage, short circuit, over-temperature

• Output trim potentiometer (adjustable output voltage)

Specifications

• Output: 12V DC, 11.5A, 138W

• Input (rated): 100-277VAC (nominal input listed as 240V)

• Operating temperature: -20°C to 40°C

• Dimensions: 169.4(L) x 61(W) x 34(H) mm

• Dimmable: No

• Certifications listed: TUV-ENEC, CE, RCM, UL(Class P), SAA, CB (plus others)
